HENRY 545 回填自流平

●低碱配方,绿色环保
●适用于地暖回填、找平
●低收缩、抗裂性能优异
●单次施工厚度可达50mm



产品介绍:

HENRY 545 回填自流平采用高强石膏、精细骨料和其他助剂等原料精制而成的绿色环保产品,良好的流动性能够快速找平地面,单次施工厚度可达50mm,24小时后,可达到平整、坚实的理想效果,可铺贴各类木地板、地毯、石塑锁扣地板、瓷砖、石材等地面材料。





特点:

●施工周期短;

●低碱配方,绿色环保;

●适用于地暖回填、找平;

●低收缩、抗裂性能优异;

●单次施工厚度可达50mm。



适用场所家庭、办公、酒店等轻载地面的基层找平。



基层处理

基层必须干燥、坚实牢固、无尘、无污染杂物为保证良好的附着力,混凝土原始基础地面等吸收性基层,使用亨历自流平界面剂进行封底处理;



技术参数:

存储期:                     6个月
流动度:                     ≥120mm
施工温度:                  5~35℃
混合比:                     产品(20kg):清水(4.8L)
可施工时间:               ≥ 20min
抗压强度(绝干):      ≥15(MPa)
抗折强度(绝干):      ≥4(MPa)



施工方法:

1、原始基层清理干净后,应选用合适的界面剂涂刷基层,当界面剂已被原始基层吸收并干固后,开始回填宝施工。

2、 在搅拌容器中倒入4.8-5.2L清水,然后慢慢加入一包20Kg的回填自流平,用搅拌机搅拌3-5分钟至均匀无团的浆状,将混合料倒出,均匀地铺开,用抹刀或专用的齿口刮板布展均匀至所需的厚度,或采用输送能力20-40KL/min的泵输送浆体至所需的厚度。

3、 搅拌后的混合料须在20分钟内完成施工,刚施工好的浆料要避免强风和阳光直射。

4、在回填宝初凝前 需排除混合时带入的空气,建议进行消泡,保证表面平整。



参考用量:产品用量约为17kg/m²/10mm,具体实际用量视施工厚度及基面实际条件而定。



注意事项:不建议在长期潮湿环境下使用,避免室外使用。本产品完全硬化后避免长时间浸泡。



包装与储存:

20kg复合纸袋包装。本品须存放于室内,注意防潮、防水、防雨和曝晒。托盘上堆放不超过8层,保质期为6个月。







HENRY 545 Backfill Self-Leveling

Product Introduction:

Uses the high strength gypsum, fine aggregate and other additives, is green product, have good liquidity, can fast automatic leveling the ground and single construction thickness of 50 mm. After 24 hours, a flat and solid base can be reached. All kinds of wood floor, carpet, ceramic tile, stone and other ground materials without special polishing requirements can be directly installed.



Features:

Primary construction thickness of 50mm;

Low shrinkage, excellent crack resistance;

Short construction period;

Can be used for heating backfill;

Low alkali formula, environmentally friendly.



Application Places:

Suitable for leveling at the base level of light ground such as home, office and hotel.

Surface Treatment:

The base must be dry, solid, dust-free, pollution-free sundries. To ensure good adhesion, absorbent surface such as concrete, it is recommended to use HENRY self - leveling back cover treatment

Technical Parameters:

Shelf life:                                                               6 months

Mobility:                                                                ≥120mm

Applied temperature:                                              5~35℃

Mixing ratio: product (20kg) :                                  water (4.8L)

Available time:                                                       ≥ 20min

Compressive strength (absolutely dry) :                    ≥15 (MPa)

Flexural strength (absolutely dry) :                           ≥4 (MPa)



Application:

1. After the original base is cleaned, appropriate primer should be selected and applied to the surface. After the primer has been absorbed by the original base and dried and solidified, start applying the backfill.

2. Pour 4.8L of water into the mixing container, then slowly add a pack of backfill. Blend with blender for 3-5 minutes and no clumps. Pour out the mixture, spread evenly and spread evenly with spatula or special toothed scraper until desired thickness, or the transmission capacity of 20-40 KL/min pump slurry to the required thickness.

3. The mixture shall be applied within 20 minutes. The freshly constructed slurry shall avoid direct sunlight and strong wind.

4. Before the initial setting of the product, the air brought in during mixing should be eliminated. It is recommended to conduct defoaming to ensure the smooth surface.



Reference Consumption:

Product consumption is about 17kg/m2•10mm. The actual amount depends on the construction thickness and actual conditions of the surface.



Notes:

This product is not recommended for long-term wet environment. Avoid outdoor use. Avoid long soaking after the product is fully hardened.



Packaging and storage:

20kg/bag. This product must be stored indoors, pay attention to moisture-proof, waterproof, rainproof and prevent insolating. Pallets should be stacked in no more than 8 layers. Shelf life is 6 months.
